- Cadre, fourche
Cadre: Haibike, SDURO Cross/Trekking, Aluminium 6061, Quick-release 5 x 135mm, Disc brake Post Mount
Fourche: SR Suntour, NEX E25-LO, Lockout, Steel spring, Travel= 63 mm, Steel steerer tube 1 1/8″, Quick release 100mm
- Moteur, batterie
Moteur: Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
Batterie: Yamaha, Lithium Ion, 500 Wh
Ecran: Yamaha, Side Switch, 1.7″ LCD, 7 functions
- Groupe
Dérailleur arrière: Shimano, Deore M6000
Freins: Tektro, T275, 180 mm, 2-piston disc brake
Manette: Shimano, Deore M6000, Rapidfire, 10 speed
- Périphériques
Cintre: Haibike Components, TheBar +, 720 mm
Potence: Haibike Components, The Stem +, A-head
Tige de selle: Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Selle: Haibike Components, TheSaddle
- Pneus, roues
Pneus: Schwalbe, Road Cruiser , 42-622, 28″ x 1.60″
Roues: Rodi, Black Rock 21, Aluminium, avec oeillets, bord creux
Poids: 24.1 kg
