- Cadre, fourche
Cadre: Haibike, SDURO HardNine, Aluminium 6061, Quick-release 5 x 135mm, Disc brake Post Mount
Fourche: RockShox, Recon TK, Remote Lockout, Steel spring, Travel= 100 mm, Steel steerer tube 1 1/8″, Quick release 100mm
- Moteur, batterie
Moteur: Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
Batterie: Yamaha, Lithium Ion, 500 Wh
Ecran: Yamaha, Side Switch, 1.7″ LCD, 7 functions
- Groupe
Dérailleur arrière: Shimano, Deore M6000
Manette: Shimano, Deore M6000, Rapidfire, 20 speed
Freins: Shimano, MT400, 180 mm, 2-piston disc brake
Plateau: FSA, Aluminium, 44 teeth
- Périphériques
Cintre: Haibike Components, TheBar+, 740 mm
Potence: Haibike Components, The Stem +, A-head
Tige de selle: Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Selle: Haibike Components, TheSaddle
- Pneus, roues
Pneus: Schwalbe, Smart Sam , 57-622, 29″ x 2.25″
Roues: Rodi, Black Rock 21, avec oeillets, bord creux, Aluminium
Poids: 22.2 kg
