- Cadre, fourche
Cadre: Haibike, SDURO HardFour, Aluminium 6061, Quick-release 5 x 135mm, Disc brake Post Mount
Fourche: SR Suntour, XCR LO, Lockout, Steel spring, Travel= 63 mm, Steel steerer tube 1 1/8″, Quick release 100mm
- Moteur, batterie
Moteur: Yamaha, PW-TE System, 250 W, 60 Nm, 20 km/h
Batterie: Yamaha, Lithium Ion, 400 Wh
- Groupe
Dérailleur arrière: Shimano, Altus M2000
Manette: Shimano, Altus M2010, Rapidfire, 9 speed
Freins: Tektro, M282, 160 mm, 2-piston disc brake
- Périphériques
Cintre: Haibike Components, TheBar + Topflat, 640 mm
Potence: Haibike Components, TheStem ++, A-head, Bar bore: 31.8 mm, 12°
Tige de selle: Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Selle: Haibike Components, TheSaddle Junior
- Pneus, roues
Pneus: Schwalbe, Table Top Performance, 57-507, 24″ x 2.25″
Roues: Rodi, FW Disc, with eyelets, hollow rim, Aluminium
Poids: 20 kg
