- Cadre, fourche
Cadre: Haibike, SDURO HardSeven, Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount
Fourche: SR Suntour, XCM34 LOR, Lockout, Steel spring, Travel= 120 mm, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, 15 x 110mm thru-axle Boost
- Batterie, moteur
Batterie: Yamaha, InTube, 400 Wh
Moteur: Yamaha, PW-SE System, 250 W, 70 Nm, 25 km/h
Ecran: Yamaha, Side Switch, 1.7″ LCD, 7 functions
- Groupe
Manette: Shimano, Altus M2010, Rapidfire, 9 speed
Dérailleur arrière: Shimano, Altus M2000
Plateau: Steel, 38 teeth
Freins: Tektro, TR180
- Périphériques
Cintre: Haibike Components, TheBar+, 740 mm
Potence: Haibike Components, The Stem +, A-head
Tige de selle: Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Selle: Haibike Components, TheSaddle
- Roues, pneus
Roues: Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Pneus: Schwalbe, Smart Sam Active , 65-584, 27.5″ x 2.60″
Poids: 24.2 kg
